Description:
| Manufacturer | Analog Devices, Inc. | Manufacturer's Part # | LT3755EMSE-2 |
|---|---|---|---|
| Categories | Integrated Circuits (ICs) | Sub-Categories | PMIC - LED Drivers |
| Series | - | Part Status | Active |
| Type | DC DC Controller | Topology | Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) |
| Internal Switch(s) | No | Number of Outputs | 1 |
| Voltage - Supply (Min) | 4.5V | Voltage - Supply (Max) | 40V |
| Voltage - Output | 75V | Current - Output / Channel | - |
| Frequency | 100kHz ~ 1MHz | Dimming | Analog, PWM |
| Applications | - | Operating Temperature | 0°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Package / Case | 16-TFSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 16-MSOP-EP |
