Description:
| Manufacturer | Analog Devices, Inc. | Manufacturer's Part # | ADUM1241ARZ |
|---|---|---|---|
| Categories | Isolators | Sub-Categories | Digital Isolators |
| Series | iCoupler® | Part Status | Active |
| Technology | Magnetic Coupling | Type | General Purpose |
| Isolated Power | No | Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 1/1 | Channel Type | Unidirectional |
| Voltage - Isolation | 3000Vrms | Common Mode Transient Immunity (Min) | 25kV/µs |
| Data Rate | 2Mbps | Propagation Delay tpLH / tpHL (Max) | 180ns, 180ns |
| Pulse Width Distortion (Max) | 8ns | Rise / Fall Time (Typ) | 2ns, 2ns |
| Voltage - Supply | 2.25V ~ 3.6V | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
