Description:
| Manufacturer | Texas Instruments | Manufacturer's Part # | LP38502ASD-ADJ |
|---|---|---|---|
| Categories | Integrated Circuits (ICs) | Sub-Categories | PMIC - Voltage Regulators - Linear |
| Series | - | Part Status | Active |
| Output Configuration | Positive | Output Type | Adjustable |
| Number of Regulators | 1 | Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 0.6V | Voltage - Output (Max) | 5V |
| Voltage Dropout (Max) | 0.37 @ 1.5A | Current - Output | 1.5A |
| Current - Quiescent (Iq) | 15µA | Current - Supply (Max) | 4mA |
| PSRR | 58dB ~ 56dB (120Hz ~ 1kHz) | Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Package / Case | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-WSON (3x2.5) |
